Focal Length
14mm – 30mm
Maximum and Minimum Aperture
f/4 - f/6.3 – f/22 - f/36
Lens Mount
Type RF Mount (Plastic)
Compatible Cameras
Canon EOS R-series, APS-C and full-frame
Minimum Focusing Distance
0.15m (5.9 in)
Maximum Magnification
0.38x (at 30mm)
Field of View, at Minimum Focus Distance
Approx. 126 × 84mm (7.2" x 4.8") at 14mm; Approx. 57 × 38mm (7.2" x 4.8") at 30mm
Angle of View (Diagonal)
Approx. 88º 30’ - 48º 50’
Lens Construction
10 elements in 9 groups
Special Elements
One UD Lens, Two Aspheric Lenses
Lens Coating
Canon SSC (Super Spectra Coating)
Filter Size Diameter
58 mm
Aperture Blades
7
Image Stabilization (yaw/pitch directions)
Provided via gyro sensors (1 each for yaw and pitch)
Focusing Drive System
Two Nano USM focus motors
Full-time Manual Focusing
Yes
(Supports both ONE SHOT AF and SERVO AF with compatible EOS R-series cameras)
Dual Pixel CMOS AF Coverage (Horizontal x Vertical)
EOS R — Approx. 88% x 100%
EOS R5/R6 — Approx. 90% x100%
EOS R7/R10/R50 — Approx. 100% x 100%
Maximum Outer Diameter x Length
Approx. 2.7 in. x 2.4 in. (69.6mm x 62mm)
Weight
Approx. 6.3 oz. / 0.4 lb. /181 g
